Water cooling LGB1100 dry oil-free screw vacuum pump motor power 22KW

Product Description

Dry screw vacuum pumps operate with two screw rotors rotating in opposite directions. This traps the medium to be pumped between the cylinder and the screw chambers and transports it to the gas discharge. The advanced screw design results in lower electric energy consumption compared to standard screw designs. It also results in a lower heat load of the compressed gas.

 Cooling can be achieved through a high performance air cooling method eliminating the need of cooling water or indirect cooling method resulting in uniform temperatures throughout the pump body, eliminating cold spots and providing a thermally stable water jacket. The advanced screw design allows for best-in-class hydrogen pumping capabilities. Water cooling can take place in form of both direct water cooling or radiator cooling with air-cooled heat exchangers.





Model			LGB140	LGB280	LGB450	LGB650	LGB800	LGB1100	LGB1500
Pumping Speed		Ls	40	70	125	180	220	305	416
		mP/h	140	280	450	650	650	790	1080
Uitimate Pressure(50Hz)		Pa	3-30Pa
Maximum exhaust pressure		bar	1.2
Motor Power(50Hz)		Kw	4	7.5	11	15	18.5	22	22
Rotate Speed		rpm	2900	2900	2900	2900	2900	2900	2900
interface	Inlet Diameter	mm	50	65	65	100	100	100	100
	outlet diameter	mm	DN32	DN32	DN40	DN50	DN50	DN65	DN65
water Cooling Mode	flow	m²/min	0.5	0.6	0.6	0.6	0.6	0.85	0.85
	pressure	MPa	0.1~0.2
	Outlet water temperature	℃	≤40
	nterface		G3/8"	G1/2"	G1/2	G1/2”	G1/2”	G1/2”	G1/2”
Noise Level		dB	575	S75	S76	S76	s76	S80	S85
Weight		Kg	230	320	500	680	780	820	100





Water cooling TXLGB series dry screw vacuum pump



Performance advantage

Energy saving: lower power consumption than similar products;

Reliable: dry structure pump chamber, mechanical varacor compression, to achieve stable process vacuum;

Environmental protection：Zero sewage discharge, no environmental pressure, save the cost of sewage treatment;

Efficiency: no pollution of solvent, easy to recover solvent, increase the benefit;

Easy maintenance: no need to do special maintenance, basic no maintenance costs, save trouble, worry;

Cooling: water saving than similar products, and the cooling temperature requirements are not harsh;

Anticorrosion: can choose nickel phosphorus Hastening alloy coating or matching chin alloy and other

overall material.
