RCP 230N Handheld And Portable Pirani Vacuum Gauge

Main Specifications

RCP 230N

Handheld and Portable Pirani Vacuum Gauge

RCP230N is specially designed by Infitech for use in non-fixed occasions or irregular and short-term use.

A hand-held portable Rani vacuum gauge was developed to measure the vacuum degree of the equipment.

The volume range is from atmospheric pressure to 1.0E-2Pa. RCP230N is equipped with a set of large-capacity lithium batteries.

It can work continuously for more than 40 hours on a single charge, and the automatic sleep and shutdown functions greatly extend the battery life.

The actual working time is extended, and the anxiety of battery depletion of conventional battery-powered Pirani vacuum gauges is relieved.

It is an ideal vacuum degree measurement for mobile inspection, field operations and equipment maintenance.

Vacuum contact materials SS316L stainless steel, tungsten, Kovar, glass

Measuring range 1.0×10-2~1.0×10+5Pa (air, N2, other gases require correction coefficients)

Measurement accuracy 1.0×10-1~1.0×10+4Pa: ±15%

1.0×10+4~1.0×10+5Pa: ±50%

Measurement repeatability 1.0×10-1~1.0×10+3Pa: 2%

1.0×10+3~1.0×10+5Pa: 5%

Data acquisition resolution 1%, response time <100ms

Temperature characteristics: working temperature 0 °C~+45°C, storage temperature -40 °C~+75°C

Power supply: built-in lithium battery; comes with +5V/4A charger; continuous operation with full charge >40 hours

Vacuum probe interface: DN16 ISO-KF (other options are optional), maximum pressure 1.5×10+5Pa

Weight 480 grams (including DN16 ISO-KF flange)

Features

The device is compact and easy to carry around

Large color LCD screen with strong data readability

Built-in high-capacity lithium battery, no external power supply required

Battery detection and real-time display, low battery alarm, charging status indication

Automatic sleep, shutdown function, time can be set

Supports a variety of units, Pa, mBar, and Torr can be flexibly selected

Supports one-piece calibration and automatically identifies gas and zero points

Support power-off memory function
