TXL-860 helium mass spectrometer leak detector

Product Introduction lPortable and easy to move lHigh pressure resistance of leak detection port lQuick helium cleaning functionWide detection range lOne click reset of leak detection status lDetection values can be stored lChinese and English menu interface lThe entire machine has reached the international advanced level

Item NO :
TXL860
Type :
Leak detector

Inquire Now

Product Details

Specification

1. Minimum detectable leakage rate: 3×10-13Pa ·m³/s

2. Leakage rate display range: 1×10⁻ ¹- 1×10-13Pa ·m³/s

3. Starting time: ≤ 3min

4. Response time: ≤ 0.5s

5. Maximum pressure at the leak detection port: 2000Pa

6. Mechanical pump pumping speed: 2m³/h

7. Power requirements: 220V, 50Hz, single-phase, 10A

8. Working environment: 5-35 ℃

9. Relative humidity: ≤ 80%

10. Boundary dimension: 560 (W) × 430 (D) × 300 (H)

11. Weight: 42kg

Main configuration

1.Imported molecular pump

2.Imported mechanical pump

3.Built in standard leak hole

4.American AD amplifier

5.Mass spectrometry dedicated module

6.Delta LCD touch color screen

helium leak detector

Leak detector-specific molecular pump, and can greatly increase the speed sensor on helium, effectively improve the clearance of the end of the helium in this time, blocking the contamination of the helium mass spectrometer chamber.

Automatic LCD touch color display, intelligent automation, convenient operation, simple and reliable.

Filament ion source, using yttria Iridium filament ion source and longer life, higher sensitivity.

Solenoid valve with a specially designed leak detector dedicated, more scientific and more reliable.

180 degrees of non-uniform magnetic field mass spectrometer chamber design to maximize the effectiveness and response time of the leak detector

Electrical components with a new modular design makes maintenance more convenient, signal interference less, better leak detection

The amplifier used by the U.S. AD amplifier, effectively reducing the leak detector noise, and improve the leak detector's sensitivity and leak effects.

The product has the rapid removal of the end of this function

TXL-860 helium mass spectrometer leak detector main technical parameters

the minimum leak rate: 5 x 10-13 Pa m3 / s,

leak rate display range: 1 × 10-3—1× 10-13 Pa • m3 / s

start-up time: ≤ 3min

Response time: ≤ 1.0s

the highest pressure leak detection port: 1500Pa

Power Requirements: 220V, 50Hz, single phase, 10A

work environment :5-35 ℃

Relative humidity: ≤ 80%

Dimensions: 560（W）×420（D）×320（H 9. ）

Weight:42kg
